VLX 100 Arched / Custom Door

VLX 100 Arched / Custom Door in Homestead, FL | TruePane Windows & Doors

The VLX 100 Arched door is what happens when a manufacturer refuses to treat an arched entryway as an afterthought. ViewLux builds this door with CNC-bent aluminum, so the curve isn’t a facsimile bolted onto a rectangular frame. It’s a single, continuous sweep of metal, cut and bent to the exact radius of your opening. We’re TruePane Windows & Doors, the authorized ViewLux installation partner serving Homestead, FL, and we’ve installed the VLX 100 in more custom homes across South Miami-Dade than we can count. If you want an entryway that looks like it belongs on a Mediterranean estate or a modern farmhouse, this is the door. Call (448) 428-7290 and we’ll measure your opening the right way.

Call (448) 428-7290

Product Overview - VLX 100 Arched / Custom Door

The VLX 100 Arched / Custom Door sidesteps the ugly compromises that plague most arched door installations. Historically, builders had two choices when a homeowner wanted a curved entryway: mill a wood frame and pray it holds its shape through two Homestead summers, or order a rectangular aluminum door and disguise the arch with a fixed transom. Both approaches fade, warp, leak, or just look like an apology. ViewLux took a different path. The VLX 100 starts as a straight extrusion of architectural-grade aluminum. A CNC bender curves the top rail to the precise radius specified on the order. The result is an arched entryway with structural continuity from threshold to apex, no seams, no patchwork. That’s what “curved architectural statement with structural precision” means in practice: the curve is load-bearing, not decorative.

We see three types of buyers for this door in Homestead. The first is the custom-home owner who has been planning the arched entry since the architect’s first sketch, and who understands that a true radius door beats a rectangular door with an arched transom every single time. The second is the remodeler replacing a failing wood arch that has swollen, rotted, or developed gaps around the hinge jamb. The third is the builder who wants a point of differentiation for a spec home in a neighborhood like Keys Gate or Waterstone, where every other house reads the same from the street. The VLX 100 gives the elevation a focal point that isn’t available from a lumberyard.

Why aluminum for a custom door? Because Homestead sits in a High Velocity Hurricane Zone. Wood and even some vinyl products struggle with repeated wet-dry cycles and sustained UV exposure. Aluminum holds its dimensions. The 0.098-inch wall thickness on the VLX 100 profiles gives the door enough mass to feel solid when it closes, but the aluminum doesn’t absorb moisture the way wood does. And when the salt air drifts in from Biscayne Bay or the Everglades gets heavy after a summer storm, aluminum doesn’t care. It just sits there and keeps working.

The profile width of 2.56 inches gives the frame a presence that reads as substantial from the curb, but it also creates room for the thermal break that separates the interior and exterior aluminum faces. That matters more than most homeowners realize: without a thermal break, an aluminum door in Homestead becomes a heat conductor into your foyer. With it, the door contributes to the home’s overall energy envelope. We’ll get into that more below.

Technical Specifications

Here’s what the VLX 100 Arched / Custom Door brings to a Homestead opening. Every dimension and option below is production-standard from verified and installed by our crew at TruePane Windows & Doors.

• Frame profile: 2.56 inches wide, extruded aluminum with a structural thermal break
• Aluminum wall thickness: 0.098 inches, consistent across the full rail and stile length
• Fabrication method: CNC-bent top rail, cut to the exact arc of your opening, no forced curves or segmented approximations
• Maximum span: Custom fabricated to order. There is no stock-size cap. If your architect drew a 12-foot arch, we order a 12-foot arc.
• Glass options: Clear, Frosted, Obscure, Low-E, Tempered, Laminated
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, Teak Wood
• Assembly standard: Factory-welded corners at the base, mechanically fastened mid-rails where the design requires
• Glazing method: Wet-glazed with structural silicone on both interior and exterior beads

Performance Features

Thermal Efficiency - The VLX 100 carries a polyamide thermal break between the exterior and interior aluminum profiles. That break interrupts conductive heat transfer, which is the single biggest reason aluminum doors used to get a bad name in South Florida. The NFRC-rated performance on this series keeps the sun’s heat from walking straight through your entryway into the air-conditioned foyer. In a Homestead August, that’s not a luxury. It’s the difference between a door that performs and a door that cooks.

Acoustic Performance - Laminated glass is the quiet option here. The interlayer between the two panes dampens mid-range frequencies, which is exactly what you want if your home faces Krome Avenue, the Turnpike extension, or any of the busier corridors through Redland or Leisure City. Even with standard glazing, the wet-set silicone beads and compression weatherstripping cut down on the air gaps that let sound sneak around the edges of the sash.

Airtightness & Weather Seal - Every perimeter joint on a VLX 100 installation done by TruePane Windows & Doors is sealed with AAMA 812 low-expansion foam. That’s not a marketing flourish. AAMA 812 is the performance spec for foam sealants used around window and door frames, and it’s the standard referenced by the AAMA 2400/2410 installation guidelines we follow on every job. The result is a door that doesn’t whistle in a stiff breeze.

Waterproofing - Homestead gets roughly 60 inches of rain a year, and hurricanes push that rain sideways. The VLX 100’s sill design works with the weatherstripping profile to keep water moving down and out, not in. After every install, our crew runs a water test on the threshold and the arch leg joints. If we find a leak, we don’t leave until it’s corrected. That’s the AAMA 2410 way, and it’s the only way we install.

Wind Resistance - The VLX 100 is wind-load rated for High Velocity Hurricane Zone requirements, which covers Homestead and all of Miami-Dade County. The laminated glass option provides impact resistance for those who want the strongest possible assembly. The arched shape has a structural advantage too: a curve distributes wind pressure more evenly than a flat rectangle, which is why arched bridges and arched doorways have survived storms for centuries.

Security & Hardware - A solid aluminum door with a multi-point lock is a meaningful deterrent, and the VLX 100 accepts multi-point hardware that secures at three points along the latch jamb. That’s not a standard deadbolt kicking into a 3-inch strike plate. It’s top, bottom, and center locking that makes a pry attack significantly harder. Talk to us about hardware options when you get a quote.

Color & Glass Options

Finishes first, because Homestead architecture spans the full range. Premium Black is the choice for contemporary builds and modern farmhouses; it reads sharp against white stucco or limewash. Pure White works on coastal and Key West inspired homes, and it doesn’t yellow under our UV load the way some painted whites do. Anodized Silver is the minimalist’s option, a true aluminum look with a matte sheen that hides water spotting. Bronze suits Mediterranean and Spanish Revival homes, especially paired with clay tile or barrel roofing. Champagne is the wildcard: warm but not yellow, formal without being stuffy. And Teak Wood gives you the look of a timber arch without the maintenance of actual wood. For Homestead specifically, we see the most requests for Bronze on older established homes east of U.S. 1 and Premium Black on new construction in the planned communities west of the Turnpike.

On glass, Clear maximizes daylight and visibility, while Frosted and Obscure give you privacy without giving up the light. Low-E rejects solar heat and UV, which fades furniture and flooring over time. Tempered meets safety glazing code for doors. Laminated is the impact-resistance choice, and in Homestead it’s the option we recommend most often, even if you’re not required to have it. A laminated lite in an arched entry door is the best defense against a wind-borne branch that turns your beautiful foyer into a debris field.

Installation by TruePane Windows & Doors in Homestead

An arched door is only as good as the opening it sits in. We’ve seen gorgeous custom doors installed by crews who set the frame out of level and then forced the door slab to fit. Within a year, the lock doesn’t catch, the reveal gaps are uneven, and the weatherstripping doesn’t meet the jamb. By then, the manufacturer has every right to deny the warranty claim, because the installation failed, not the product. That’s the cost of cutting corners on installation: your warranty vanishes.

TruePane Windows & Doors installs every VLX 100 to AAMA 2400/2410 standards. That means the opening gets a full inspection before the new frame goes in: we check the rough opening dimensions against the order, verify the substrate is sound, and identify any water intrusion or rot that needs remediation before we set a single screw. Homestead homes, especially older ones east of Krome, often carry hidden moisture damage around door openings from years of hurricane season exposure. We find it and fix it before it becomes a warranty problem.

During installation, we set the frame dead level, dead plumb, and dead square. That’s not aspirational language; it’s the floor of what we accept. We’ll shim, pack, and adjust until a 4-foot level reads true in both planes. Then we anchor through the frame into the structural framing, fill the full perimeter with AAMA 812 low-expansion foam, and install the sealant beads per the AAMA 2400 specification. After the door slab is hung and adjusted, we run the water test and check the operable stroke. Then we clean up, haul off the old door, and walk the homeowner through the hardware and finish care.

Homestead has its own building department and its own local amendments to the Florida Building Code. We pull permits on every install and coordinate inspections so you don’t have to. A door package that’s wind-load rated is required here, and the VLX 100 meets the HVHZ standard. Your insurance company may also offer credits for impact-rated openings; keep your documentation from the install and talk to your agent.

Frequently Asked Questions - VLX 100 Arched / Custom Door

Get a Quote - VLX 100 Arched / Custom Door in Homestead

If you’re ready to bring a true arched entryway to your Homestead home, the first step is a measurement, not a guess. Call (448) 428-7290 and we’ll schedule a free on-site measurement at your property anywhere in Homestead, Florida City, or the surrounding South Miami-Dade area. We’ll take the opening dimensions, confirm your radius, discuss glass and finish options, and give you a written line-item quote. No pressure, no games, just a precise number for a door that will change the way your home meets the street.

Written by the team at TruePane Windows & Doors, serving Homestead, FL as an authorized ViewLux installation partner.
